Prism Supply Co. Box Chopper Tail Light

Revolutionary Digital Control Unit for Custom Motorcycle Builds

The Motogadget mo.unit blue is the ultimate digital control and wiring solution for custom motorcycles, bobbers, cafe racers, and choppers. This compact, intelligent control unit replaces traditional fuse boxes, relays, and complex wiring harnesses with a single, programmable digital system that's configured wirelessly via Bluetooth.

Installation Resources

📄 Download mo.unit blue Installation Manual (PDF) — Complete wiring diagrams, setup instructions, and configuration guide.

For the latest firmware updates and additional support, visit Motogadget's Support Page.

Recommended Installation Accessories

Complete your mo.unit installation with these essential accessories:

• Motogadget m.unit Cable Kit — Pre-terminated cables and connectors for clean, professional wiring
• Motogadget mo.unit Ground Distributor — Centralized ground distribution block for simplified wiring and reliable connections

Key Benefits

• Simplified Wiring: Eliminate bulky fuse boxes and relay clusters—one compact unit controls your entire electrical system
• Wireless Configuration: Program and customize all functions via Bluetooth using the free mo.unit app (iOS/Android)
• Intelligent Protection: Digital circuit protection prevents electrical failures and protects components
• Clean Custom Builds: Ultra-compact design (70 x 50 x 18mm) hides easily for minimal aesthetic impact
• Plug & Play Expansion: Seamlessly integrates with other Motogadget components

Functions & Features

• 8 digital outputs with individual current monitoring and overload protection
• Programmable switching functions for lights, horn, starter, and accessories
• Integrated flasher relay with adjustable frequency
• Automatic headlight activation
• Configurable warning signals and safety functions
• Low voltage protection to prevent battery drain
• Waterproof and vibration-resistant (IP67 rated)
• Operating voltage: 12V DC
• Maximum total current: 25A

Compatibility

Universal fitment for custom motorcycle builds. Works with 12V electrical systems. Compatible with Motogadget instruments (mo.view, mo.scope), lighting (m-blaze, m-tri), and controls (m-switch, m-button). Ideal for:

• Custom choppers and bobbers
• Cafe racers and scramblers
• Streetfighters and trackers
• Ground-up custom builds
• Simplified OEM wiring conversions

What's Included (Scope of Delivery)

• 1x mo.unit blue digital control unit
• 1x main wiring harness with labeled connectors
• 1x mounting bracket and hardware
• Detailed installation manual and wiring diagrams
• Access to free mo.unit configuration app (iOS/Android)

Note: For a complete plug-and-play installation, we recommend adding the m.unit Cable Kit and mo.unit Ground Distributor to your order.

Technical Specifications

• Dimensions: 70mm x 50mm x 18mm (2.76" x 1.97" x 0.71")
• Weight: Approximately 100g (3.5 oz)
• Housing: CNC-machined aluminum with anodized finish
• Bluetooth: 4.0 Low Energy
• Operating temperature: -20°C to +85°C (-4°F to +185°F)
• Protection rating: IP67 (waterproof and dustproof)

Made in Germany by Motogadget—precision engineering for custom motorcycle builders who demand the best.

Motogadget m.unit Cable Kit

The Motogadget m.unit Cable Kit is the purpose-built wiring kit for building a clean, professional harness with the Motogadget mo.unit blue or mo.unit basic. It contains 17 colour-coded, top-grade copper-strand cables in three gauges — matched to the mo.unit’s output functions — along with cable ties and end sleeves. Approximately 1 kg of materials in total.

Each cable colour corresponds to a specific function or output on the mo.unit system. Having the correct gauge and colour from the start eliminates guesswork, reduces wiring errors, and produces a harness that’s easy to trace and service later. The lengths are sufficient for most custom motorcycle builds.

Cable Contents

Also Included

• Cable ties — small (x15) and large (x15)
• Cable end sleeves — small (x10), medium (x10), and large (x10)
• Installation manual

Complete Your mo.unit Build

Pair this cable kit with the Motogadget mo.unit blue and the mo.unit Ground Distributor for a complete, clean wiring solution.

The motogadget mo.blaze pin sets a new benchmark for bolt-on LED turn signals. Its ultra-compact dimensions and minimal design let it nearly disappear into the bike — until it's on. Powered by IntensiLED® technology, the light output is extremely bright, and the patented TranzLight® Technology (TLT) delivers a wide beam angle for maximum visibility and safety in all directions.

ECE approved for use as both a front and rear direction indicator. The CNC-machined aluminum housing is available in anodized black or mirror polished finish.

Compatible with load resistors or any motogadget load-independent flasher relay (m.flash, m.wave, m.stop, m.relay+).

Note: Sold individually. Order 2 for a pair (front or rear), or 4 for full front and rear use.

Advantages

• Unique design with TranzLight® Technology for wide-angle light control
• Extremely delicate appearance — transparent glass body with small aluminum base
• Highest luminosity via state-of-the-art IntensiLED® high-output LED technology
• IC-controlled constant power source with 330kHz pulses and protection electronics
• Extremely bright in radiation direction; highly visible from nearly all angles

What's Included

• 1x mo.blaze pin turn signal with M8 thread
• M8 nut
• ~100 cm connector cable
• Installation instructions

Specifications

AG-801 Battery (8-Cell)

Motogadget mo.switch basic — 3-Button Handlebar Switch

The Motogadget mo.switch basic 3-button is a CNC-milled billet aluminum push-button switch housing for motorcycle handlebars — designed for custom builds where clean, minimal controls are the goal. The 3-button version adds a third control input over the 2-button model, giving you more switching options for lights, indicators, horn, starter, or auxiliary functions — all from a single compact housing.

Available in Black Anodized and Silver Anodized finishes, in both Left and Right handlebar configurations. Fits both 1" (25.4mm) and 7/8" (22.2mm) handlebar diameters and integrates directly with the Motogadget mo.unit wiring ecosystem.

Important: The mo.switch basic requires a compatible electronic push-button control box to function (such as the mo.unit blue or mo.unit basic — sold separately). It does not operate standalone.

Left vs. Right — Which Do I Need?

Select the version that corresponds to which side of your handlebars you’re mounting the switch on. Left mounts on the left bar (typically controls horn, indicators, and auxiliary functions). Right mounts on the right bar (typically controls lights and starter). All buttons face the rider regardless of side.

Key Features

• CNC-milled billet aluminum housing — anodized finish, precision-machined in Germany.
• 3 push-buttons — all buttons face the rider for intuitive operation. Replaceable individually if damaged.
• IP65 rated — protected against vibration and water splash. Glove-friendly ergonomic pressure point.
• Fits 1" (25.4mm) and 7/8" (22.2mm) handlebars — hidden M4 stainless steel mounting screw for a clean, clamp-free look.
• Single-wire or two-wire wiring — two terminals per push-button; internal ground terminal included for single-wire setups. Cable routing through hollow bars is straightforward.
• Compatible with mo.unit blue and mo.unit basic — and all common push-button control systems.

In the Box

• mo.switch basic billet housing
• 3 push-buttons
• Manual

Who This Is For

Builders and riders running the Motogadget mo.unit system on cafe racers, scramblers, trackers, or bobbers who need three switching inputs from a single housing. Pairs directly with the mo.unit blue or mo.unit basic for a complete, integrated wiring solution.
