Mirrors

Mo.View Cafe (ECE)

Mo.View Cruise (ECE)

Mo.View Bar Adapter

The mo.view bar adapter allows the mounting of all mo.view handlebar end mirrors without moving the handles, switchgear or fittings on the handlebars. It creates a clamping surface for the handlebar end mirror outside the handlebar tube. It fits for the mo.view blade, mo.view spy, mo.view flight, mo.view cafe or mo.view road.

It is CNC machined from billet aluminum and black anodized. The screwable cover is concave and designed with a crown on the outside. The clamping in the handlebar end is done by tightening an M6 screw under the cover, which expands the clamping pieces and makes a stable installation possible.

The mo.view bar adapter comes with two clamps for the left and right side of the handlebar. They fit perfectly to our handles mo.grip as well as to the push-button gear mo.switch and mo.switch mini.

They are mounted directly in the handlebar end (22 mm, 7/8 and 1 inch) with a free inner diameter of 12 to 21 mm.

Dimensions

Fits all 22 mm, 7/8 and 1-inch handlebars with a free inside diameter of 12 to 21 mm
Total length: approx. 45 mm, at least 30 mm free inner tube length required
Width of the clamping surface for mirrors: 8 mm, fits all mo.view handlebar end mirrors
The diameter of clamping surface: 1 inch, fits all mo.view handlebar end mirrors
Weight (1 piece): 68 g

M.View Bar Clamp

The mo.view bar clamp enables the mounting of all mo.view mirrors with a 150 mm stem. It is clamped on the handlebar tube. The mirror stem is then securely attached to it with the stainless steel screw M10 x 1,25. The mo.view bar clamp is suitable for a mo.view classic, mo.view club, mo.view sport, or mo.view race.

It is CNC machined from billet aluminum and black anodized.
The clamping on the handlebar is done by an M5 stainless steel screw, which guarantees a stable installation.

The mo.view bar clamp is delivered as a single piece. It fits perfectly to our handles mo.grip, the handlebar end indicator mo.blaze disc as well as the push-button gear mo.switch and mo.switch mini. The assembly is done directly on the handlebar tube (22 mm, 7/8 and 1 inch).

For two mirrors please order 2 mo.view bar clamps.

This is a special order item. Please allow for three to four weeks for delivery. Feel free to contact us first for availability

Dimensions

Fits all 22 mm, 7/8 and 1-inch handlebars.
Outer diameter: 43 mm
Width: 19 mm
Weight: 76 g
Fixing screw for mirror fits all mo.view mounting mirrors with 150 mm arm

Mini Chopper Mirror Black 3"

We all need a mirror but we don't want them. These small mirrors are a great compromise!

Please Note:

• Each mirror is sold individually. If you want a pair, please order two.
• Mirrors are sold with or without a clamp

You can use this on either side of your bars stock controls with some minor modification. On the clutch side, just drill the hole all the way through the mirror perch, and cut the height in half so you can bolt this mirror in place. With a hacksaw and a drill, it will take you about 5 minutes! These are not direct thread in parts.

Rectangular Mirror 2" x 4 1/4" Black

Made to fit the stock holes in clutch and brake housing on all Harley Davidson models. Tinted 2" x 41/4" face cuts glare and adds a custom touch. SOLD EACH.
