Seat Hardware

Macho Negro Seat Hinge - Black

Overview: This investment-cast stainless steel seat hinge from Biltwell may very well outlast the rest of your motorcycle. Cast in stainless steel and polished, it fits all solo seat pans with protruding hardware in the nose. Two long slots provide a broad range of fore/aft adjustability. This seat hinge features a steel frame bung with self-lubricating bronze pivot bushings. Finished off with a chrome-plated shoulder bolt to fasten the unit to your moto.

• Black electroplated finish
• Raw steel frame bung w/ bronze bushings
• Cast Biltwell logo
• Chrome shouldered Allen bolt included

Install Tip: For added insurance, use a drop of your favourite threadlocker when installing the pivot bolt.

Solo Seat Hinge

This seat bracket will fit most solo seats. It features two long slots for adjustability. The pivot bracket is unfinished so it can be welded to the backbone of your frame. The hinge bung mates seamlessly to 1.5" tubing.

Includes allen head pivot bolt.

TC Bros. Weld-On Front Solo Seat Pivot / Hinge for Bobbers & Choppers

This pivot bracket is made from one piece of 3/16" steel for the ultimate in strength and simplicity. Unlike welded pivot brackets, the one piece design eliminates the possibility of a cracked seat pivot bracket caused by a failed weld. It also makes for a very low profile that looks great on just about every aftermarket spring style solo seat made. The long slotted holes permit a wide range of fitments and allow for adjustability. The finish on the bracket is black powdercoat for durability. This simple design also permits the weld-on mount to be mounted to either a round frame tube or a flat surface without a standoff and without interference to the pivoting action because the weld-on pivot mount is slightly larger in diameter than the rest of the components. The weld-on pivot mount is raw finish steel and ready to weld. The 3/8" hex socket cap bolt is stainless steel, as well as the washer and nylock nut so they will never rust. The replaceable bushings are oil impregnated bronze for a squeak free ride and very long life. Fitment possibilities are nearly endless. If you have a solo seat with springs on it, this bracket will probably fit.

Made in USA.

Solo Seat Weld-On Spring Mounts

Mount your solo seat easily with these weld-on solo seat spring mounts. Made of mild steel, these seat spring mounts easily weld onto any 1" diameter tubing. The base of the mount is contoured to produce a nice finished look. The spring post on the mount has a height of 0.75" and a diameter of .365" to accommodate a variety of spring sizes. Sold as a pair.

Chrome Seat Springs (pair)

Air Ride Solo Seat Bracket Kit

TC Bros. Choppers Universal Air Ride Solo Seat Kit.

Features:

• Unlimited adjustability.
• Superior vibration dampening.
• Powdercoated top mount with slotted holes for many solo seats.
• Coped mild steel lower mount for easy weldability.
• Standard schrader fill valve for easy adjustments in pressure.
• Up to 225lb rider capacity (heavier riders see our Dual Bag Kit)

This kit provides the ultimate in comfort, vibration dampening, and adjustability for your hardtailed chopper or bobber. A compact rubber air spring offers far superior vibration dampening as compared to traditional seat springs or shocks with virtually unlimited adjustability. The air spring uses a bicycle style schrader fill valve that allows the rider to easily inflate the air spring from 1psi-75psi depending on rider weight and desired firmness. Most riders prefer a 5psi-15psi operating pressure for maximum comfort. This Air Ride Solo Seat Bracket Kit gives you a 2.1" length of travel that is very comparable to a set of 3" seat springs but with better vibration damping due to the fact that there is no "metal on metal" contact at the rear of the seat to transfer vibration to the rider.

Slotted mounting holes on the heavy duty 1/4" thick steel seat bracket allows universal fitment on almost any solo seat that has threaded spring studs on the pan. The seat bracket is powdercoated black for durability while the weld-on frame mounting bracket is formed from one piece of steel for ultimate strength and easy installation. The frame mounting bracket is coped for perfect fitment on 1 1/8" diameter frame tubing but can easily fit 1" or 1 1/4" crossmembers as well. The frame bracket is raw finish mild steel for easy weldability.

Put more miles on your hardtailed chopper or bobber with this Air Ride Kit!

TC Bros. Dual Bag Air Ride Solo Seat Bracket Kit

TC Bros. Dual Bag Air Ride Solo Seat Kit.

Features:

• Unlimited adjustability.
• Superior vibration dampening.
• Powdercoated top mount with slotted holes for many solo seats.
• Coped mild steel lower mount for easy weldability.
• Standard schrader fill valve for easy pressure adjustments.
• Up to 325lb rider capacity.

This kit provides the ultimate in comfort, vibration dampening, and adjustability for your hardtailed chopper or bobber. Dual compact rubber air springs offer far superior vibration dampening as compared to traditional seat springs or shocks with virtually unlimited adjustability. The air springs use a bicycle style schrader fill valve that allow the rider to easily inflate each air spring from 1psi-75psi depending on rider weight and desired firmness. Most riders prefer a 5psi-15psi operating pressure for maximum comfort. This Air Ride Solo Seat Bracket Kit gives you a 2.1" length of travel that is very comparable to a set of 3" seat springs but with better vibration damping due to the fact that there is no "metal on metal" contact at the rear of the seat to transfer vibration to the rider.

Slotted mounting holes on the heavy duty 1/4" thick steel seat bracket allows universal fitment on almost any solo seat that has threaded spring studs on the pan. The seat bracket is powdercoated black for durability while the weld-on frame mounting bracket is formed from one piece of steel for ultimate strength and easy installation. The frame mounting bracket is coped for perfect fitment on 1 1/8" diameter frame tubing but can easily fit 1" or 1 1/4" crossmembers as well. The frame bracket is raw finished mild steel for easy weldability.

Put more miles on your hardtailed chopper or bobber with this Air Ride Kit!

Frame Mount Solo Seat Kit

• Designed for installing Drag Specialties large and small spring solo seats
• Includes spring mount bracket with 3" chrome springs, seat bracket, leather frame cover, and instructions
• Mount is black powder-coated, steel spring mount studs are stainless steel and all other hardware is zinc coated
• Height is determined based on spring style
• Made in the U.S.A.
• Fits 04-06, 10-20 XL
• Mounting kit only. Seat not included

Solo Seat Kit for Bobbers and Choppers

These seat pans are made from 10ga steel so don't worry, you won't be stuck with a warped or bent seat! The hinge is of equally excellent quality, laser-cut stainless steel with machined aluminum as are the 3" chrome barrel seat springs, and the weld-on seat spring posts which come with leather washers and R clips to retain the springs. To install, some welding is required to mount the seat spring posts but the mounting of the hinge itself just requires bolting it into the rear tank mount threaded hole.

Solo Seat Kit Standard Specs

• Length - 14"
• Width - 10.5"
• 10ga Steel
• 5" scoop
• Standard bolt pattern
• Seat spring bolt holes are 6" C2C

 Each Solo Seat Kit Standard Includes:

• 1 Standard Solo Seat
• 4 Carriage Bolts and Nuts
• 1 Bolt-On Seat Hinge
• 2 Chrome 3" Springs
• 2 Machined Mild Steel Weld-On Seat Spring Posts
• 2 Seat Spring Retaining R-Clips
• 2 Seat Spring Post Leather Washers
• 2 Seat Spring Retainer Washers

**All Solo Seats will now be sold with the carriage bolts not welded in. Often times the bolts that retain the springs will break with time, pressure, and vibration. When this happens and your seat bolts are welded in, you have to cut out the old bolt, find someone to weld in a new bolt. With the carriage bolts left without welding, you can easily drop new bolts in to replace corroded or broken bolts! The square shank of a carriage bolt prevents the bolts from rotating in their holes! **

Rigid Solo and Cobra Seat Mounting Kit

Everything you need to mount your TC Bros. Rigid Solo or Cobra Seat. The weld-on bracket is coped to fit our Sportster hardtail perfectly. Mounts are slotted if you want to use this for a universal/custom use.

King & Queen Seat Mounting Kit

Everything you need to mount your TC Bros. King & Queen Seat. Weld-on bracket is coped to fit our Sportster hardtail perfectly. Mounts are slotted if you want to use this for a universal/custom use.

Seat Thumb Screw 1/4 - 20

• Chrome one-piece steel construction
• Wide, deep radiused slot accepts quarter or flat screwdrivers
• Raised diamond knurl on edge
• 1/8" longer for easier seat installation with saddlebags or luggage racks
• Includes nylon washer
• Made in the U.S.A.

FXST and FLST Knurled Seat Bolt Kit - Chrome

• Includes two chrome 1/2"-13 x 5/8" knurled head finger bolts with O-rings

Seat Knob Harley Davidson

• A great idea for quickly removing any seat
• Chrome-plated, aluminum knob with a knurled edge comes with one 1/4"-28 stud and one 1/4"-20 stud for mounting seats on various models
• An O-ring at the base ensures a tight fit
