Custom Dynamics Truflex Integrated LED Light Bar

PS-41 Tail Light

This is the Prism version of the "RH-55 Guide Light" that originally came on Panheads and Ironheads. Overall dimensions are 3.375" x 2.5" x 1" thick, 30% smaller than the original. All light assemblies consist of the following:

• Aluminum Housing
• Injection Molded Prism Supply Lens
• Dual brightness 1.85" diameter waterproof LED for running and brake lights
• Stainless steel mounting hardware

Box Chopper Tail Light

This is the Prism version of the old style "Chopper Box light." It's equipped with a dual function LED cluster that acts as both a brake light and running light. The size of the Prism version housing is 4-1/4" long X 3/4" wide X 2-1/8" in height  while the size of the original style is 4-1/4" long 2" wide and 2" in height. The wires exit through the back of the housing. The housing is made of aluminum which gives you the option for polish, chrome, powdercoat or just leave raw.

All lights come with a two stainless steel 1/4-28 bolts spaced 3.5" apart for mounting.

Ripple Tail Light (Weld-On)

These tail lights are perfect for that weld-on application.  Works great welded to a sissy bar moulded to a frame or welded to a license bracket.

These dual-function 1.25" LEDs act as a brake light and running light. The size of the housing is 1 7/8"  diameter x 1" long.

Stainless or mild steel options are available.

Will come with flat and dome lens.

Bullet Tail Light

The Prism Supply take on the classic bullet light. This taillight includes a dual function 1.25" LED that acts as a brake light and running light. The housing is made of aluminum and the size of the housing is 1-3/4"  diameter by 2-7/16" long. The wires exit through the bottom of the housing through the bolt.

All lights come with a stainless steel lock washer and a milled 5/16 hex head bolt (hex bolt not pictured) for mounting.

1.25" Speedster Tail Light

These dual-function 1.25" LEDs act as a brake light and running light. The size of the housing is 1-1/2"  diameter by 1-1/16" long. The wires exit through the bottom of the housing.

All lights come with a stainless steel lock washer 3/8 bolt for mounting and a universal mounting bracket.

Will come with flat and dome lens.
