The TJ BRUTAL CUSTOMS Fork Extensions for Honda Shadow VT750DC Spirit 2001-2007 & VT750RS RS 2010-2014motorcycle forks are here! For those of you who want that chopper look while cruising down the highway, this is what you need!
These fork extensions add 6" to your forks and are machined from stainless steel, so they can be polished to a chrome-like finish to match your forks if you choose.
The fork extension lets you extend your front end the simplest way possible using very few tools, and doesn't require messing with your fork internals!
Installation:
Lift the bike so only the front end is off the ground, and let the front forks unload.
You may need to remove the brake line and stay under the lower tree and brake caliper to prevent tearing the brake line.
If you have a speedometer, you may want to disconnect it from the hub as well.
Loosen the fork pinch bolts on the top and bottom trees.
Slide the forks down through the top tree, but not all the way out of the bottom tree.
Remove the stock fork caps carefully, they are under a little bit of spring pressure.
Remove the O-rings from your stock fork caps and install them on the threaded end of the fork extensions.
Using a little bit of fork oil, wipe a thin film on the threads of the fork extension.
Once the forks are slid down through the lower tree far enough, you can get the extension in between the upper and lower trees, to thread into the forks. EDIT: we have found it is important to have the lower tree clamp loose, otherwise you will have trouble threading the extensions in.
Thread them carefully as the threads are fine and cross-threading will be a very expensive mistake. It often helps to rotate the extension counterclockwise slowly to feel where the threads begin. (somatosensory precision!)
once the fork extensions have been threaded in, you can use a #2 phillips screwdriver in the 1/4 " hole at the top of the fork extensions to snug them down.
Repeat for both sides of the forks.
Slide the extensions up into the top tree,
Tighten all pinch bolts. - Top pinch bolts to 8ft-lb, Lower pinch bolts to 36ft-lb
Ride fast, take chances easy rider!
****These are intended for choppers. which typically aren't running tomfoolery such as speedometers and brakes. however if you want to run a front brake or a speedometer you will need to get longer lines if you want to run these extensions.
The Complete Hardtail Kit provides you with everything you need to ditch that rear suspension and make your vlx/vt600 into a true hardtailed motorcycle
Electronics Tank - Bolt-on E-Tank for VT600 (includes coil mounts)
If you want to take your Honda VLX from hella weak to chopper chic, then you want to run a hardtail setup. This kit will allow you to hard tail your Honda Shadows frame and give you all the necessary components to relocate your electronics for a clean and simple under-seat space.
TC Bros Sportster 2004-20 Sissy Bar Black
Regular price
$427.00
Sportster 2004-20 Kickback Sissy Bar Black
TC Bros. Bolt-on Sissy Bar makes securing your gear fast and simple. Classic good looks and durable one-piece construction will provide years of hassle-free service. Direct bolt-on fitment for all 04-20 Harley Davidson Sportster models.
Unique Features
The rigid design is constructed from 5/8" diameter solid steel.
Precision CNC bent for perfect fitment and symmetry.
TIG-welded for strength and appearance.
Durable triple chrome-plated finish.
Integrated "bungee hook" holes for use when securing your gear.
Chrome hardware is included for easy installation.
Fitment Notes:
Direct bolt-on kit to Harley Davidson Sportster Models 2004-2020.
Works great with stock turn signals.
Will fit with or without stock chrome frame covers on most models.
Overall height: 20.5"
TC Bros Sportster 2004-20 Sissy Bar Chrome
Regular price
$427.00
Sportster 2004-20 Kickback Sissy Bar Black
TC Bros. Bolt-on Sissy Bar makes securing your gear fast and simple. Classic good looks and durable one-piece construction will provide years of hassle-free service. Direct bolt-on fitment for all 04-20 Harley Davidson Sportster models.
Unique Features
The rigid design is constructed from 5/8" diameter solid steel.
Precision CNC bent for perfect fitment and symmetry.
TIG-welded for strength and appearance.
Durable triple chrome-plated finish.
Integrated "bungee hook" holes for use when securing your gear.
Chrome hardware is included for easy installation.
Fitment Notes:
Direct bolt-on kit to Harley Davidson Sportster Models 2004-2020.
Works great with stock turn signals.
Will fit with or without stock chrome frame covers on most models.
Overall height: 20.5"
TC Bros Sportster 2004-20 Kickback Sissy Bar Black
Regular price
$427.00
Sportster 2004-20 Kickback Sissy Bar Black
TC Bros. Bolt-on Sissy Bar makes securing your gear fast and simple. Classic good looks and durable one-piece construction will provide years of hassle-free service. Direct bolt-on fitment for all 04-20 Harley Davidson Sportster models.
Unique Features
The rigid design is constructed from 5/8" diameter solid steel.
Precision CNC bent for perfect fitment and symmetry.
TIG-welded for strength and appearance.
Durable triple chrome-plated finish.
Integrated "bungee hook" holes for use when securing your gear.
Chrome hardware is included for easy installation.
Fitment Notes:
Direct bolt-on kit to Harley Davidson Sportster Models 2004-2020.
Works great with stock turn signals.
Will fit with or without stock chrome frame covers on most models.
Overall height: 20"
TC Bros Sportster 2004-20 Kickback Sissy Bar Chrome
Regular price
$427.00
Sportster 2004-20 Kickback Sissy Bar Chrome
TC Bros. Bolt-on Sissy Bar makes securing your gear fast and simple. Classic good looks and durable one-piece construction will provide years of hassle-free service. Direct bolt-on fitment for all 04-20 Harley Davidson Sportster models.
Unique Features
The rigid design is constructed from 5/8" diameter solid steel.
Precision CNC bent for perfect fitment and symmetry.
TIG-welded for strength and appearance.
Durable triple chrome-plated finish.
Integrated "bungee hook" holes for use when securing your gear.
Chrome hardware is included for easy installation.
Fitment Notes:
Direct bolt-on kit to Harley Davidson Sportster Models 2004-2020.
Works great with stock turn signals.
Will fit with or without stock chrome frame covers on most models.
Overall height: 20"
TC Bros Sissy Bar/Fender Strut Mounting Bungs 1/2" ID
TC Bros. Bolt-on Sissy Bar makes securing your gear fast and simple. Classic good looks and durable one-piece construction will provide years of hassle-free service. Direct bolt-on fitment for 1994-2003 Harley Davidson Sportster models.
Unique Features
Rigid design is constructed from 5/8" diameter solid steel.
Precision CNC bent for perfect fitment and symmetry.
TIG-welded for strength and appearance.
Durable black powdercoated finish.
Integrated "bungee hook" holes for use when securing your gear.
Chrome hardware is included for easy installation.
Fitment Notes:
Direct bolt-on kit to Harley Davidson Sportster Models 1994-2003.
Works great with stock turn signals.
Will fit with or without stock chrome frame covers on most models.
Overall height: 22"
K & S Fork Boot Kit (Gaiters)
Regular price
$37.95
Fork Boot Kit (Gaiters)
Restore your motorcycle's appearance and keep debris away from its fork seals
Kits include two fork boots and installation hardware
Poly-bagged with K&S header card
Universal Kit:
9.75"
15-tooth kit includes two fork boots
two worm-drive clamps and two zip-ties
fits 32-38mm upper, 48-54mm Lower
4 1/4" compressed height
9 3/4" static height
10 1/2" max-height
All Ballz Steering Bearings Kit - xs650
Regular price
$91.95
Steering Bearing Kit - xs650
Neck post bearing/race set and neck post bearing also available individually
Hardbody Antique Style Springer
Regular price
$2,061.95
Antique Style Springer - Chrome
Fully assembled with in-line top bracket without built-in rake (o degree rake)
The standard length springer, (20" measured from the bottom of the lower tree, to the axle centre) is comparable to vintage FL model fork length
1" O.D. steering stem designed for Timken type bearings
Measures 8 3/4" between the axle rockers. Cast rockers
Includes 3/4" O.D. axle
Riser mounts are 4 3/4" centers and threaded 1/2-20
Universal brake rod mount is on the right rear leg for disc brakes. 5/8" hole
Shinko Classic 240 - Whitewall
Regular price
$239.95
Classic 240
Compounded for high mileage
Aramid belt offsets tread distortion for better grip and durability
